High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Brand Name : TOM

Model Number : JP-J

Certification : ISO9001:2000, ISO14001, OHSAS18001, CE, CO

Place of Origin : China (Mainland)

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T

Delivery Time : 20 working days for single machine

Packaging Details : Non-fumigation wooden case inserted Iron Shelf, suitable for long time sea delivery

Material : Stainless Steel 304

Feeding speed : 60-120bottles/minute

Motor : Frequency motor

Table diameter : 1000mm or 1200mm

Delivery port : Shanghai, China

Standard : Meet GMP standard

Service : Engineer is available to install and debug the equipment at customer site.

Contact Now

JP-J Bottle Feeding Table

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Major characteristics:

The turn plate of this machine adopts adjustable inverter of limitless speed to rotate, making all the bottles enter into conveyor belt in order under the rotary tangential force, reduce labor, and raise production efficiency. This machine can work when the power is on, easily operating. It can be widely used for glass bottles, plastic bottles and polyester bottles for pharmaceutical, agrochemical, food, and chemical industries etc. It is an ideal equipment for small, medium and large factory.

Technical Parameter:

No	Items	Performance
01	Power supply	AC 220V; 50Hz (may customized)
02	Power	1.5 Kw
03	Production Capacity	60-120 containers/minute
04	Diameter of turntable	Φ1200mm
05	Suitable diameter of bottles :	Φ40mm~Φ100mm
06	Machine weight	300kg
07	Machine dimension (L×W×H)	1700MM1300MM1350MM
08

Machine picture in side

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Machine picture in front

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

This feeding table can be customized for food industry which added dust production cover.

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

The dust cover can prevent the dust enter into bottle during running

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Delivery: packed by wooden case and delivery to Shanghai Port, the wooden case is suitable for long-term sea delivery

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Tom factory picture

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Customer visiting in Tom factory

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table

Customer visit Tom's exhibition booth

High Speed Automatic Rotary Plastic Glass Bottle Feeding Table
